XML external entity (XXE) attacks are one of the OWASP Top Ten security risks. XXE attacks are caused by XML parsers that have entity processing enabled. Here’s an example of a simple Ruby program that has entity processing enabled in Nokogiri, its XML parser:
This allows our XML parser to read the contents of our local filesystem, the key point being that this occurs because the NOENT flag is enabled. When we run the program, we see contents of /etc/passwd (limited to the first 10 lines for brevity):
$ ruby xxe.rb | head -n 10
<?xml version="1.0"?>
<!DOCTYPE root [
<!ENTITY users SYSTEM "file:///etc/passwd">
]>
<root>
<child>##
# User Database
#
# Note that this file is consulted directly only when the system is running
# in single-user mode. At other times this information is provided byIf we ran the program with NOENT disabled, we’d see the following:
$ ruby xxe.rb | head -n 10
<?xml version="1.0"?>
<!DOCTYPE root [
<!ENTITY users SYSTEM "file:///etc/passwd">
]>
<root>
<child>&users;</child>
</root>In this case, we see that there’s still a reference to the users entity, and we haven’t read the contents of our local filesystem.
This raises a question: what does NOENT actually mean?
At first glance, the naming is a bit counterintuitive. NOENT looks like it means something like “no entities,” but we are processing our users external entity when that flag is enabled.
Luckily, we don’t have to search far in Nokogiri’s source code to see how NOENT is used. Nokogiri is partially implemented in Java, and we can find this code snippet in its XmlDomParserContent.java source file:
In the same file, we find FEATURE_NOT_EXPAND_ENTITY defined like so:
To summarize what we’ve discovered so far: when NOENT is enabled, the FEATURE_NOT_EXPAND_ENTITY feature is turned off, and this is when we see our entity expanded with contents from the local filesystem. When NOENT is disabled, the FEATURE_NOT_EXPAND_ENTITY feature is turned on, and we don’t read contents from the local filesystem.
That’s a lot of consecutive negatives! Let’s reword it for clarity: when our flag is enabled, the feature which expands entities is turned on. Put this way, the behaviour is a bit more clear – we see the contents of the local filesystem because our entity-expanding feature is enabled.
Still, this doesn’t answer our original question – why the name NOENT? To answer that, we can look at Apache documentation related to the FEATURE_NOT_EXPAND_ENTITY definition shown previously. Under the definition of the http://apache.org/xml/features/dom/create-entity-ref-nodes feature, we expect the following behaviour when FEATURE_NOT_EXPAND_ENTITY is set to true:
Create EntityReference nodes in the DOM tree. The EntityReference nodes and their child nodes will be read-only.
And when it’s set to false:
Do not create EntityReference nodes in the DOM tree. No EntityReference nodes will be created, only the nodes corresponding to their fully expanded sustitution [sic] text will be created.
In other words, when NOENT is enabled, it means that we don’t expect to see an EntityReference node in our parsed content, and our parser should replace an entity with its definition (in the case of our example, replace the users node with /etc/passwd). If NOENT is disabled, it means we do expect to see our entity in our parsed content, and so we still see a reference to users in the output of our parser.
In conclusion: the NOENT flag does mean “no entities”, as in, “no references to entities should exist in our parsed XML.” This is why our parser replaces it with the contents of /etc/passwd. This naming convention leaves plenty of room for confusion, which is why fixing the names of parser flags is actually on the Nokogiri roadmap!
